Motherboard Branded Q77 H2 AM. High Perfomance. LGA 1155. 2nd and 3rd Gen. (Serial/PCI) Dual PCI Express. Gigabit LAN. 3.0 USB. 3.0 PCI Express.

Price: ₹9,999 - ₹3,999.00
(as of Sep 24, 2024 23:59:11 UTC – Details)

Q77H2-AM Motherboard. Q77 Express Chipset Smart Response Technology, Smart Connect Technology Rapid Start Technolog Supports vPro Technology Dual-channel DDR3 Memory architecture Supports DDR3 1600*/1333/1066 non-ECC, Un-buffered SDRAM Memory * Due to the operation system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation 1 X PCI Express X16 Gen 3.0 slot(s) 1 X PCI Express X16 Gen 2.0 slot(s) 1 X PCI Express X1 Gen 2.0 slot(s) 1 X PCI slot(s) *The second PCIE X16 only support bandwidth X4 6-Channel HD audio CODEC Realtek ALC662 6-channel High Definition audio CODEC Support by Q77 Express Chipset 4 X USB 3.2 Gen 1×1 port(s) up to 5Gb/s —- Back Panel 2 port(s) —- Onboard 2 port(s) 10 X USB2.0 port(s) Up to 480 Mb/s —- Back Panel 4 port(s) —- Onboard 6 port(s)
Supports DDR3 1600*/1333/1066 non-ECC, Un-buffered SDRAM Memory
GIGABIT Lan. 3X Pci Express. (1X3.0 & 1X 2.0) 1X Mini Pci E
6-Channel HD audio CODEC Realtek ALC662 6-channel High Definition audio CODEC
6X SATA Slot 1X PATA Slot.
USB 3.0 Header 4X Ram Slot.
1X Serial Port
3X Display Output. (2X DP & 1X DVI)
2X Ps2 Port
6X USb Port (4X USb 2.0 & 3X USb 3.0
