My Tridev 18V 20A 360W DC Switching Switch Power Supply for Power Supply Strip, CCTV (Silver) 18volt 20amp 360 watt

Price: ₹3,000 - ₹1,499.00
(as of Oct 02, 2024 05:15:17 UTC – Details)

Product Description

My Tridev 18V 25A 450W DC Switching Switch Power Supply for Power Supply Strip, CCTV (Silver) 18volt 25amp 450 watt

Parameter

Input: AC 100V~120V / 200V~260V 50/60HzOutput Voltage : DC 18V ( ±10% adjustable, 33.2V~37.8V)Output Current: 25A maxOutput Wattage: 450W maxFix Screw Hole Diameter: 2.5mm (0.1inch)Working temperature: -10℃ ~50℃ （-50 ℉ ~ 122℉）Storage temperature: -20℃ ~ 60℃ （-68 ℉ ~ 140℉）Environmental humidity: 10-95%

Kindly note

We suggest the max use of power should be no more than 80% of the full loads, other wise, the power supply’s span life will be shortened. We recommend you to use this 18V 25A 450W power supply to power devices less than 300W.110V/220V must be selected by switch before using to avoid damaging. Please change the switch to 110V for USA/CA and 220V for EUR.

Package included

1 x 18V 25A Power Supply

Superior Safety

Built-in safeguards to protect against over voltage, over current, overheat, short-circuit, which will provide ultimate protection for you and your devices.

Stable Output

Built-in advanced synchronous rectifier smart chip and EMI filter, convert fluctuating voltage to stable voltage, effectively reduce electromagnetic interference.

Three Output Channels

With three independent output channels, it can power more devices. The maximum output of each channel can reach 25A 450W. Total output power of the three channels is 25A 450W.

Intelligent Temp control

It comes with built-in cooling fan and temperature detector. Cooling fan will automatically run when the inner temperature reaches 113°F (45℃), which makes heat dissipation more efficient and silent.

HOW TO USED POWER SUPPLY

Input wire has to be connected L & N point, if there is an earthing wire then you can also use that.Check whether the led light on the right side is on.Put v- negative wire at the output point (wire color can be black), then you put positive wire on v+, (the color of the wire can be red)With the help of adjustable switch in this power supply, you can up and down the voltage up to 10% (keep in mind that it can become free by using more)

Connection:-

L: FireWireN: zero lineG: ground wire- V: load negative+ V: load positive

AC Input Voltage :110V/220V ±15% (Switch Selection) ；/ DC output voltage:18V
Safety features: Automatic overload cut-off, over Voltage cut-off, automatic thermal cut-off, short circuit protection.
The power supply fan does make a noise and the speed of the fan is load based. So the higher the load, the faster the fan runs, the louder the noise.
Great for LED Strips, 3D Printer, ham radio transceiver, CCTV cameras, audio amplifier, wireless router, ADSL Cats, HUB, audio/ video power supply. Indoor use only!
